(These parameters may later be set from a HMI.) For the first trials, I left the field username and password blank to reduce the possible sources of errors.

#Estructura siemens simatic s7 1200 code#

In region _setMQTTConfigParams_ I set the most important parameters for the MQTT instance, I am simply doing this in the source code rather than in the DB because I wanted to separate the most important ones and have them clearly arranged. This includes setting the topic and the message. To work with a single MQTT instance I prepared s very simple scheduler, which copies the tags to the "LMqtt_Data" DB prior to call the MQTT instance (see region _schedulerPrepareData_). In my case, I wanted to transmit two different temperatures under two different topics: There you can set all the necessary parameters, which are all (more-or-less) self-explaining.

TcpConnParam and mqttParam requires the data-types which are already initialised in the Lmqtt_Data DB (see PLC types for definition). I enabled the system clock memory bytes and passed the 1Hz bit as an input to publish, which means that the PLC posts a message once a second.

Depending on the application you need to trigger the publisher in a certain interval to post the messages to the broker. Every time publish faces a rising-edge the PLC will publish a message to the broker. The required data types for enable is self-explaining, it takes TRUE as input to activate the client, publish also takes a boolean value. TIA will ask you to create a new instance DB for this FB and shows the input and output placeholder-arguments afterwards. Then call the DB "LMqtt_Publisher_DB" in your project (see Region _MQTTSend_). Setting up the library in the TIA portal is simple, just open the library and copy the Types, DBs and FBs to your local project. The S7-1200 and S7-300 can act as a MQTT publisher, but the traffic is sent in plain text, only the S7-1500 supports message cryptography. As already described above, MQTT works on top of the TCP/IP stack, which means that it also supports SSL/TLS encryption to secure the communication.

#Estructura siemens simatic s7 1200 download#

Siemens now offers a library for their S7-1200, S7-1500 and S7-300 PLCS, which can easily be imported into own projects ( Download Library here). The data exchange is topic oriented, publishers can publish messages under specific topics and subscribers subscribe to topics whose messages they want to receive.Īttaching Simatic-S7 PLCs to a MQTT infrastructure is quite simple. The clients can act either as publishers or subscribers, or both. Simatic S7-1200 as MQTT client (publisher role) The MQTT library for the Simatic PLC is taken from Siemens (from official Industry Support Portal) and as a broker I am using the hbmqtt library written in Python.

#Estructura siemens simatic s7 1200 how to#

In this article I will shortly introduce how to setup the Simatic S7-1200 as a MQTT client (publisher role) and publish data to a MQTT broker on my local network. The clients can decide by themselves whether a message is important for them, based on the topics they have subscribed. It's main purpose is to exchange messages between clients and a server (broker). MQTT (short for Message Queue Telemetry Transport) is an open standard (ISO/IEC PRF 20922) and is based on the publish-subscribe pattern. Implementations and libraries exist for nearly every hardware, such as Arduino, Raspberry, PC, Smartphone, PLCs, etc. MQTT is a lightweight Machine-to-Machine (M2M) communication protocol often used in Industry 4.0 environments and IoT applications.
